ACR1151-FS24LSTACKPRO

Stackable design allows you to maximize limited floor space while enjoying the full storage convenience of an independent refrigerator and freezer

78.5" H x 24.0" W x 23.0" D

(199cm H x 61cm W x 58cm D)

OVERVIEW

  • Pharmaceutical all-refrigerator features complete stainless steel construction inside and out for lasting durability
  • Separate refrigerator and freezer cooling in one slim-fitting footprint
  • Both models are equipped with factory-installed probe holes for user-provided monitoring equipment
  • Factory installed locks provide security you can count on
  • Customizable design can accept additional options, including temperature alarms, data loggers, and thermometers
  • -20°C capable all-freezer
  • Some assembly required

SPECIFICATIONS

Overview
Height of Cabinet 78.5" (199 cm)
Width 24.0" (61 cm)
Depth 23.0" (58 cm)
Depth with door at 90° 45.0" (114 cm)
Capacity 12.4 cu.ft. (351 L)
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Voltage/Frequency 115 V AC/60 Hz
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator-Freezer
Door Swing RHD
Reversible No
Adjustable Shelves Yes
Interior Light Yes
Refrigerator - Interior Height 50.25" (128 cm)
Refrigerator - Interior Width 19.38" (49 cm)
Refrigerator - Interior Depth 17.75" (45 cm)
Refrigerator - Capacity 11.0 cu.ft
Refrigerator - Shelf Type Chrome
Refrigerator - Shelf Qty 6
Refrigerator - Temperature Range 2° to 8°C
Refrigerator - Refrigerant Type R600a
Refrigerator - Refrigerant Amount 1.66 oz.
Freezer - Interior Height 14.38" (37 cm)
Freezer - Interior Width 13.5" (34 cm)
Freezer - Interior Depth 13.25" (34 cm)
Freezer - Capacity 1.4 cu.ft
Freezer - Shelf Type Wire
Freezer - Shelf Qty 1
Thermostat Type Digital + Dial
Fan Type Interior
Freezer - Temperature Range -20 to -15ºC
Freezer - Refrigerant Type R134a
Freezer - Refrigerant Amount 1.5 oz.

AVAILABLE UPGRADES

Interior
LockBoxSS - Interior locking compartment
Interior drop-down compartment with combination lock for use in SCR610BL, SCR1156, FFAR12W, or FFAR121SS
Exterior
TT - Installed thermometer
ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
Alarm
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
DL1 - Factory installed data logger
USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
Extra key
Extra keys available for purchase
DT - Digital thermostat
Install a digital thermostat with external readout for precise temperature management
DL1 - Factory installed data logger
USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
HUM - Humidity sensor
Humidity sensor with min/max readout
California residents:
click here for information on Proposition 65

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or accucoldinfo@summitappliance.com

DESCRIPTION

Accucold's stackable PRO series refrigerator-freezer combinations offer space-saving cooling solutions for general purpose use.

Sized at just 24" wide, the ACR1151-FS24LSTACKPRO combines two conveniently designed general purpose units into one slim-fitting footprint. Pharmaceutical all-refrigerator ACR1151PRO offers 11 cu.ft. of storage, with a self-closing glass door and adjustable cantilevered shelving. Frost-free operation minimizes user maintenance, with an internal fan to ensure more even temperature distribution. The cabinet and interior are constructed from stainless steel for lasting durability and easier cleanup. Compact FS24LPRO all-freezer utilizes a static manual defrost system.

Both models include locks for added security, with two keys included for each unit. Hospital grade cords with 'green dot' plugs offer added convenience for busy facilities, ensuring the cords are not easily dislodged from the wall socket. Factory-installed probe holes are included on both units to allow users to install their own monitoring devices.

All Accucold STACKPRO units ship in three boxes and require some minor assembly upon delivery. Additional stacked combinations can be created by ordering virtually any two units with our StackRack. These units can also be customized with a variety of refrigeration options, including NIST calibrated thermometers, USB data loggers, open door alarms, and much more. To create a custom combination, contact our sales team at 718-893-3900.


FEATURES

Space-saving design
Allows you to create a full refrigerator-freezer with independent controls in a slim-fitting footprint
ACR1151PRO all-refrigerator
Pharmaceutical refrigerator with self-closing glass door, LED lighting, and stainless steel construction inside and out
FS24LPRO freezer
Compact manual defrost all-freezer with flat door liner and wire shelf
Access ports
Refrigerator and freezer include a 3/8" factory-installed probe hole to allow users to connect their own monitoring equipment
Factory installed locks
Both units are equipped with front locks, with two keys included for each unit
Easy assembly
Unit ships in three boxes for customer to install the StackRack on the bottom refrigerator/freezer and place and secure the other unit on top
Anti-tip bracket included
StackRack ships with anti-tip bracket for easy aftermarket installation
Foamed-in-place cabinets
Designed to ensure a sufficiently insulated interior
Magnetic door gaskets
Quality door gaskets ensure a tight seal for energy savings and improved performance
Approved for use in the USA and Canada
ETL and ETL-C listed for North American sales
100% CFC free
Environmentally friendly design with no ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet 78.5" (199 cm)
Width 24.0" (61 cm)
Depth 23.0" (58 cm)
Depth with door at 90° 45.0" (114 cm)
Capacity 12.4 cu.ft. (351 L)
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Voltage/Frequency 115 V AC/60 Hz
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator-Freezer
Door Swing RHD
Reversible No
Adjustable Shelves Yes
Interior Light Yes
Refrigerator - Interior Height 50.25" (128 cm)
Refrigerator - Interior Width 19.38" (49 cm)
Refrigerator - Interior Depth 17.75" (45 cm)
Refrigerator - Capacity 11.0 cu.ft
Refrigerator - Shelf Type Chrome
Refrigerator - Shelf Qty 6
Refrigerator - Temperature Range 2° to 8°C
Refrigerator - Refrigerant Type R600a
Refrigerator - Refrigerant Amount 1.66 oz.
Freezer - Interior Height 14.38" (37 cm)
Freezer - Interior Width 13.5" (34 cm)
Freezer - Interior Depth 13.25" (34 cm)
Freezer - Capacity 1.4 cu.ft
Freezer - Shelf Type Wire
Freezer - Shelf Qty 1
Thermostat Type Digital + Dial
Fan Type Interior
Freezer - Temperature Range -20 to -15ºC
Freezer - Refrigerant Type R134a
Freezer - Refrigerant Amount 1.5 oz.

AVAILABLE UPGRADES

Interior
LockBoxSS - Interior locking compartment
Interior drop-down compartment with combination lock for use in SCR610BL, SCR1156, FFAR12W, or FFAR121SS
Exterior
TT - Installed thermometer
ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
Alarm
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
DL1 - Factory installed data logger
USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
Extra key
Extra keys available for purchase
DT - Digital thermostat
Install a digital thermostat with external readout for precise temperature management
DL1 - Factory installed data logger
USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
HUM - Humidity sensor
Humidity sensor with min/max readout
California residents:
click here for information on Proposition 65

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or accucoldinfo@summitappliance.com
