12 lb. Drain-Free Icemaker

SKU: BIM25H34

No drain required for more flexibility in placing the icemaker

DISCONTINUED- REPLACED BY BIM26H34

33.75" H x 15.18" W x 21.0" D
(86cm H x 39cm W x 53cm D)

Overview
Height of Cabinet	33.5" (85 cm)
Height to Hinge Cap	33.75" (86 cm)
Width	15.18" (39 cm)
Depth	21.0" (53 cm)
Depth with Handle	22.5" (57 cm)
Depth with door at 90°	34.0" (86 cm)
Capacity	1.0 cu.ft. (28 L)
Defrost Type	Manual
Door	Stainless Steel
Cabinet	Stainless Steel
US Electrical Safety	UL
Canadian Electrical Safety	ULC
Amps	1.5
Voltage/Frequency	115 V AC/60 Hz
Weight	100.0 lbs. (45 kg)
Shipping Weight	105.0 lbs. (48 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101058474
Icemaker
Door Swing	RHD
Reversible	Yes
Daily Ice Production	12.0 lbs. (5 kg)
Ice Storage Capacity	12.0 lbs. (5 kg)
Ice Shape	Crescent
Number of Ice Cube Sizes	1
Refrigerant Type	R600a
Refrigerant Amount	0.63 oz.
High Side PSI	250.0
Low Side PSI	110.0
Interior Height	11.5" (29 cm)
Interior Width	10.0" (25 cm)
Interior Depth	12.63" (32 cm)
Level Legs	4

Exterior

LHD - Left hand door swing

Latch - Factory-installed door latch requires manual release to open unit

No pump or drain required

Convenient design allows more flexibility in positioning the unit

Built-in capable

Make the best use of space by installing your icemaker under the counter and flush with other cabinets

Complete stainless steel exterior

Door, cabinet, and kickplate feature full 304 grade stainless steel construction made in the USA

Professional handle

Sleek handle in brushed stainless steel is horizontally mounted for a modern look

Mid-sized capacity

Produces and stores up to 12 pounds of ice per day cycle

Insulated storage bin

Ice stays solid longer in this cold-protected bin

Removable bin

Bucket can be removed for fast and easy cleaning

Storage compartment

Includes lower compartment for storing non-refrigerated items

Reversible door

User-reversible design allows you to change the door swing to better accommodate your setup

Right angle plug

Design allows you to plug the unit in flush against the wall socket with no need to add extra depth

Manual defrost

Static cooling system helps to keep ice frozen for longer periods of time compared to other systems

Ice scoop included

Large plastic ice scoop included for your convenience

Sealed back

Flush design with no exposed coils for easier cleanup

Defrost drain included

Rear-mounted drain for added convenience

Height adjustable

Unit can be adjusted from 33 1/2" to 34 1/2" for the perfect undercounter fit

Fully finished cabinet

Allows the icemaker to be used freestanding

100% CFC free

Environmentally friendly design without ozone-damaging chemicals

SUMMIT brings convenient luxury under the counter with built-in icemakers in complete stainless steel.

Sized at just 15 1/8" wide, the BIM25H34 features a front-breathing design for built-in installation, but also has a fully finished cabinet to allow freestanding use. The cabinet and user-reversible door are wrapped in 304 grade stainless steel for professional style built to last, with a sleek handle mounted horizontally to finish the look. This unit includes a lower non-refrigerated storage compartment with a swing door. It has a sealed back and right angle plug to allow more flush installation.

Inside, the BIM25H34 can produce up to 12 pounds of crescent-shaped ice per day, storing it inside a removable insulated bin. The static manual defrost cooling system allows ice to stay solid longer. No drain or pump is required for use, offering more flexibility in where you place the unit. The BIM25H34 ships with a connection hose. Other hardware should be supplied by your plumber.

With its complete stainless steel construction and low maintenance design, the BIM25H34 is a great way to finish any undercounter kitchen space. For this unit sized at 32" for use under ADA compliant counters, see the BIM25H32.

BROCHURE w/ DRAWINGS
BIM25H34.pdf

TECHNICAL DRAWING (.dwg)
BIM25H34_ICE_MAKER__A-C_2000_.dwg

USE & CARE
BIM24OS_BIM25H32_34_ENG_and_FR_01.29.21.pdf

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or info@accucold.com

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
