FF31L7BI

Commercial unit 306f3be253affc7d1f0b385aa144fcc2faa4dffeee4d2148a5b353fc300c77f8
This unit is designed for commercial use. It meets the U.S. Department of Energy (DOE) commercial energy standards but may not meet DOE residential standards.

Includes a digital thermostat for precise temperature control

26.13" H x 17.0" W x 19.0" D

(66cm H x 43cm W x 48cm D)

OVERVIEW

  • Flexible design allows built-in or freestanding use
  • Meets UL-471 commercial electrical standards
  • Digital thermostat for easier and more precise temperature management
  • Factory-installed lock provides security you can count on
  • Automatic defrost operation minimizes user maintenance
  • Compact size is ideal for use on top of counters

SPECIFICATIONS

Overview
Height of Cabinet 25.5" (65 cm)
Height to Hinge Cap 26.13" (66 cm)
Width 17.0" (43 cm)
Width with Door Open 17.75" (45 cm)
Depth 19.0" (48 cm)
Depth with door at 90° 34.75" (88 cm)
Capacity 2.5 cu.ft. (71 L)
Defrost Type Automatic
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Weight 58.0 lbs. (26 kg)
Shipping Weight 61.0 lbs. (28 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator Features
Door Swing RHD
Reversible Yes
Shelf Type Chrome
Shelf Qty 4
Adjustable Shelves Yes
Thermostat Type Digital
Refrigerant Type R600a
Refrigerant Amount 0.6oz.
High Side PSI 270.0
Low Side PSI 103.0
Interior Light Yes
Dimensions
Interior Height 21.25" (54 cm)
Interior Width 13.5" (34 cm)
Interior Depth 14.75" (37 cm)
Compressor Step Height 7.5" (19 cm)
Compressor Step Width 13.5" (34 cm)
Compressor Step Depth 5.0" (13 cm)

AVAILABLE UPGRADES

Exterior
Extra key
Extra keys available for purchase
SCD - Self-closing door
Protect interior contents and reduce energy waste with the Self Closing Door Option
PH - Probe Hole
Factory installed probe hole for customer supplied monitoring devices
DL1 - Factory installed data logger
USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
Alarm
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
HG - Hospital grade cord
Add a hospital grade cord equipped with green dot plug with the HG suffix
LHD - Left hand door swing
Door reversal to left hand swing
ODA - Open door alarm
Add an open door alarm to audibly buzz when the door is left ajar.
Latch for door
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
TT - Installed thermometer
ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
DL1 - Factory installed data logger
USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or accucoldinfo@summitappliance.com
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.

DESCRIPTION

SUMMIT COMMERCIAL offers a quality line of compact refrigeration designed and constructed for reliable use in commercial applications.

The FF31L7BI is a compact all-refrigerator that can be used built-in or freestanding. The commercial design meets UL-471 electrical standards. The unit comes in a white exterior finish with a reversible door. A factory installed front lock offers keyed security, while the rear features a sealed metal cover for improved sanitation.

Inside, the 2.5 cu.ft. FF31L7BI utilizes automatic defrost operation for low maintenance use. Four removable chrome shelves offer convenient storage, while the flat door liner allows you to store deeper items. The digital thermostat is located inside and can be managed in Celsius or Fahrenheit. Interior LED lighting offers an attractive, energy efficient view of the interior in a soft blue hue.

With its ideal dimensions and user-friendly features, the FF31L7BI offers added convenience to the usual compact refrigerator.

FEATURES

Built-in capable
Front-breathing system allows the unit to be used built-in
Automatic defrost
No-frost convenience for reduced user maintenance
Digital thermostat
Electronic controls offer more precision in temperature management, with a readout viewable in Celsius or Fahrenheit
Factory-installed lock
Keyed lock for a secure interior
Adjustable chrome shelves
Rearrange the refrigerator space to fit any sized item or remove shelves for simple cleanup
LED lighting
Interior LED lighting offers an energy efficient view in an attractive blue hue
Reversible door
User-reversible door swing for added flexibility
Flat door liner
No door shelving allows the unit to accommodate deeper items
Sealed back
Space-saving design with no exposed coils in the rear offers easy cleanability
Commercial design
Meets UL-471 electrical standards
Fully finished cabinet
Allows the unit to be used freestanding
100% CFC free
Environmentally friendly design does not contain ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet 25.5" (65 cm)
Height to Hinge Cap 26.13" (66 cm)
Width 17.0" (43 cm)
Width with Door Open 17.75" (45 cm)
Depth 19.0" (48 cm)
Depth with door at 90° 34.75" (88 cm)
Capacity 2.5 cu.ft. (71 L)
Defrost Type Automatic
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Weight 58.0 lbs. (26 kg)
Shipping Weight 61.0 lbs. (28 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator Features
Door Swing RHD
Reversible Yes
Shelf Type Chrome
Shelf Qty 4
Adjustable Shelves Yes
Thermostat Type Digital
Refrigerant Type R600a
Refrigerant Amount 0.6oz.
High Side PSI 270.0
Low Side PSI 103.0
Interior Light Yes
Dimensions
Interior Height 21.25" (54 cm)
Interior Width 13.5" (34 cm)
Interior Depth 14.75" (37 cm)
Compressor Step Height 7.5" (19 cm)
Compressor Step Width 13.5" (34 cm)
Compressor Step Depth 5.0" (13 cm)

AVAILABLE UPGRADES

Exterior
Extra key
Extra keys available for purchase
SCD - Self-closing door
Protect interior contents and reduce energy waste with the Self Closing Door Option
PH - Probe Hole
Factory installed probe hole for customer supplied monitoring devices
DL1 - Factory installed data logger
USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
Alarm
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
HG - Hospital grade cord
Add a hospital grade cord equipped with green dot plug with the HG suffix
LHD - Left hand door swing
Door reversal to left hand swing
ODA - Open door alarm
Add an open door alarm to audibly buzz when the door is left ajar.
Latch for door
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
TT - Installed thermometer
ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
DL1 - Factory installed data logger
USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout

DOWNLOADS

Download
BROCHURE w/ DRAWINGS
FF31L7BI.pdf
Download
TECHNICAL DRAWING (.dwg)
FF31L7_REFRIGERATOR__A-C_2000_.dwg
Download
USE & CARE
FF31L7BI_manual.pdf
Download
MSDS INFORMATION
MSDS_R600a_C.pdf
This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or accucoldinfo@summitappliance.com
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
