FFAR10PLUS2

Includes a NIST calibrated thermometer with a current and high/low temperature readout

54.88" H x 25.0" W x 23.0" D

(139cm H x 64cm W x 58cm D)

OVERVIEW

  • Over 10 cu.ft. of storage in a slim 24" footprint
  • NIST calibrated thermometer displays the current and high/low temperature to the nearest tenth of a degree
  • Internal fan-forced cooling for more temperature stability
  • Advanced precision with digital temperature controls
  • Made in Europe

SPECIFICATIONS

Overview
Height of Cabinet 54.5" (138 cm)
Height to Hinge Cap 54.88" (139 cm)
Width 25.0" (64 cm)
Depth 23.0" (58 cm)
Depth with Handle 24.75" (63 cm)
Depth with door at 90° 45.38" (115 cm)
Capacity 10.1 cu.ft. (286 L)
Defrost Type Automatic
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Other Energy Info 120 Volts / 60 Hz.
Amps 1.5
Voltage/Frequency 115 V AC/60 Hz
Weight 150.0 lbs. (68 kg)
Shipping Weight 155.0 lbs. (70 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator Features
Door Swing RHD
Reversible Factory Reversible
Shelf Type Wire
Shelf Qty 4
Adjustable Shelves Yes
Thermostat Type Digital
Fan Type Interior
Refrigerant Type R134a
Refrigerant Amount 3.0oz.
High Side PSI 290.0
Low Side PSI 70.0
Level Legs Qty 2
Interior Light Yes
Temperature Range 2 to 8ºC / 36 to 46ºF
Dimensions
Interior Height 48.0" (122 cm)
Interior Width 21.0" (53 cm)
Interior Depth 17.75" (45 cm)
Compressor Step Height 6.0" (15 cm)
Compressor Step Width 21.0" (53 cm)
Compressor Step Depth 5.5" (14 cm)

AVAILABLE UPGRADES

Exterior
DTMEDF
Change thermostat to read in Fahrenheit (no charge)
PH - Probe Hole
Factory installed probe hole for customer supplied monitoring devices
DL1 Temperature Logger
USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
HG Cord
Add a hospital grade cord equipped with green dot plug with the HG suffix
HUM Humidity Sensor
Humidity sensor with min/max readout
Latch
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD
Door reversal to left hand swing
ODA Open Door Alarm
Add an open door alarm to audibly buzz when the door is left ajar.
SCD Self-Closing Door
Protect interior contents and reduce energy waste with the Self Closing Door Option
KEY
Extra keys available for purchase
Alarm
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
DL2 Temperature Logger
USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
Lock
AC Keypad
Keypad lock powered by appliance power cord for keyless security
KEYPAD
Battery-powered keypad lock installed for keyless security
Interior
LockBox24
Interior lift-up compartment with combination lock for use in FF7 or FFAR10 models
California residents:
click here for information on Proposition 65

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or accucoldinfo@summitappliance.com

DESCRIPTION

Accucold's PLUS2 Series refrigerators come specially featured for use doctors’ offices, medical clinics, nursing stations, and other general purpose facilities that require more temperature assurance than a standard refrigeration unit provides.

The FFAR10PLUS2 is an upright mid-sized all-refrigerator with a generous 10 cu.ft. capacity. Made in Europe, it comes in a white exterior finish with keyed lock conveniently located on the side for convenient accessibility. The digital thermostat is located in the kickplate for easy and precise temperature management.

The unit uses automatic defrost operation and includes two internal fans for stabilized cooling. Adjustable wire shelves offer flexible storage, with a flat door liner to help accommodate larger trays. The FFAR10PLUS2 includes a  traceable thermometer calibrated to NIST standards in our ISO/IEC 17025:2005 laboratory. It displays the current, minimum, and maximum temperature to the nearest tenth degree viewable in Celsius or Fahrenheit. The buffered temperature probe is stored in a glycol-filled bottle to ensure the temperature reading best reflects the temperature of other stored freezer contents.

The FFAR10PLUS2 can be further customized with a variety of options, including data loggers, alarms, and more. Contact our sales team for more information.

*NOTE: This unit's thermostat is pre-set for Celsius. If you prefer Fahrenheit, add complimentary option DTMEDF or let your sales representative know upon order.


FEATURES

Large capacity
10.1 cu.ft. capacity in a 24" footprint
Automatic defrost
Reduced maintenance with auto defrost system
NIST calibrated temperature display
Thermometer provides continuous display of the current and high/low temperature to the nearest tenth of a degree, with a readout switchable from Celsius to Fahrenheit at the touch of a button
Buffered temperature probe
Thermometer probe is encased in a glycol-filled bottle to better simulate the temperature of stored contents instead of refrigerator air temperature
Digital thermostat
Electronic controls ensure easy and intuitive temperature management
Internal fan
Fan-forced cooling ensures the unit is evenly cooled from top to bottom
Factory installed lock
Side-mounted for convenient security
Adjustable shelves
Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup
Interior light
Turn the light on and off with a convenient rocker switch
Magnetic door gasket
Quality door gaskets ensure a tight seal for energy savings and improved performance
Foamed-in-place cabinet
Designed to ensure a sufficiently insulated interior
Approved for use in the USA and Canada
ETL and ETL-C listed for North American sales
Factory reversible door
Standard unit ships with a right hand door swing. For a left hand door swing, add option LHD upon order (due to its construction, this door is not reversible in the field)
100% CFC Free
Environmentally friendly design with no ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet 54.5" (138 cm)
Height to Hinge Cap 54.88" (139 cm)
Width 25.0" (64 cm)
Depth 23.0" (58 cm)
Depth with Handle 24.75" (63 cm)
Depth with door at 90° 45.38" (115 cm)
Capacity 10.1 cu.ft. (286 L)
Defrost Type Automatic
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Other Energy Info 120 Volts / 60 Hz.
Amps 1.5
Voltage/Frequency 115 V AC/60 Hz
Weight 150.0 lbs. (68 kg)
Shipping Weight 155.0 lbs. (70 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator Features
Door Swing RHD
Reversible Factory Reversible
Shelf Type Wire
Shelf Qty 4
Adjustable Shelves Yes
Thermostat Type Digital
Fan Type Interior
Refrigerant Type R134a
Refrigerant Amount 3.0oz.
High Side PSI 290.0
Low Side PSI 70.0
Level Legs Qty 2
Interior Light Yes
Temperature Range 2 to 8ºC / 36 to 46ºF
Dimensions
Interior Height 48.0" (122 cm)
Interior Width 21.0" (53 cm)
Interior Depth 17.75" (45 cm)
Compressor Step Height 6.0" (15 cm)
Compressor Step Width 21.0" (53 cm)
Compressor Step Depth 5.5" (14 cm)

AVAILABLE UPGRADES

Exterior
DTMEDF
Change thermostat to read in Fahrenheit (no charge)
PH - Probe Hole
Factory installed probe hole for customer supplied monitoring devices
DL1 Temperature Logger
USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
HG Cord
Add a hospital grade cord equipped with green dot plug with the HG suffix
HUM Humidity Sensor
Humidity sensor with min/max readout
Latch
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD
Door reversal to left hand swing
ODA Open Door Alarm
Add an open door alarm to audibly buzz when the door is left ajar.
SCD Self-Closing Door
Protect interior contents and reduce energy waste with the Self Closing Door Option
KEY
Extra keys available for purchase
Alarm
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
DL2 Temperature Logger
USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
Lock
AC Keypad
Keypad lock powered by appliance power cord for keyless security
KEYPAD
Battery-powered keypad lock installed for keyless security
Interior
LockBox24
Interior lift-up compartment with combination lock for use in FF7 or FFAR10 models

DOWNLOADS

California residents:
click here for information on Proposition 65

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or accucoldinfo@summitappliance.com
