FFAR25L7BICSS

Commercial unit 306f3be253affc7d1f0b385aa144fcc2faa4dffeee4d2148a5b353fc300c77f8
This unit is designed for commercial use. It meets the U.S. Department of Energy (DOE) commercial energy standards but may not meet DOE residential standards.

Includes a digital thermostat for precise temperature control

20.75" H x 17.0" W x 19.13" D

(53cm H x 43cm W x 49cm D)

OVERVIEW

  • Flexible design allows built-in or freestanding use
  • Meets UL-471 commercial electrical standards
  • Stainless steel exterior offers long-lasting durability
  • Digital thermostat for easier and more precise temperature management
  • Factory-installed lock provides security you can count on
  • Compact size is ideal for use on top of counters
  • Automatic defrost operation minimizes user maintenance

SPECIFICATIONS

Overview
Height of Cabinet 20.25" (51 cm)
Height to Hinge Cap 20.75" (53 cm)
Width 17.0" (43 cm)
Width with Door Open 17.75" (45 cm)
Depth 19.13" (49 cm)
Depth with door at 90° 34.25" (87 cm)
Capacity 1.7 cu.ft. (48 L)
Defrost Type Automatic
Door Stainless Steel
Cabinet Stainless Steel
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Weight 55.0 lbs. (25 kg)
Shipping Weight 58.0 lbs. (26 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator Features
Door Swing RHD
Reversible Factory Reversible
Shelf Type Chrome
Shelf Qty 2
Adjustable Shelves Yes
Thermostat Type Digital
Refrigerant Type R600a
Refrigerant Amount 0.6oz.
High Side PSI 270.0
Low Side PSI 103.0
Interior Light Yes
Temperature Range 34°F to 43°F
Dimensions
Interior Height 16.5" (42 cm)
Interior Width 13.75" (35 cm)
Interior Depth 15.0" (38 cm)
Compressor Step Height 8.0" (20 cm)
Compressor Step Width 13.75" (35 cm)
Compressor Step Depth 6.0" (15 cm)

AVAILABLE UPGRADES

Exterior
DL1 - Factory installed data logger
USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
TT - Installed thermometer
ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
Latch for door
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
ODA - Open door alarm
Add an open door alarm to audibly buzz when the door is left ajar.
LHD - Left hand door swing
Door reversal to left hand swing
Extra key
Extra keys available for purchase
SCD - Self-closing door
Protect interior contents and reduce energy waste with the Self Closing Door Option
PH - Probe Hole
Factory installed probe hole for customer supplied monitoring devices
DL1 - Factory installed data logger
USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
Alarm
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
HG - Hospital grade cord
Add a hospital grade cord equipped with green dot plug with the HG suffix
This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or accucoldinfo@summitappliance.com
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.

DESCRIPTION

SUMMIT COMMERCIAL offers a quality line of compact refrigeration designed and constructed for reliable use in commercial applications.

The FFAR25L7BICSS is a compact all-refrigerator that can be used built-in or freestanding. The commercial design meets UL-471 electrical standards.  The unit comes with a stainless steel door and fully wrapped stainless steel cabinet. A factory installed front lock offers keyed security, while the rear features a sealed metal cover for improved sanitation.

Inside, the FFAR25L7CSS utilizes automatic defrost operation for low maintenance use. Two removable chrome shelves offer convenient storage, while the flat door liner allows you to store deeper items. The digital thermostat is located inside and can be managed in Celsius or Fahrenheit. Interior LED lighting offers an attractive, energy efficient view of the interior in a soft blue hue.

With its ideal dimensions and user-friendly features, the FFAR25L7CSS offers added convenience to the usual compact refrigerator.

FEATURES

Built-in capable
Front-breathing system allows the unit to be used built-in
Stainless steel finish
Solid construction for lasting durability and a professional look
Automatic defrost
No-frost convenience for reduced user maintenance
Digital thermostat
Electronic controls offer more precision in temperature management, with a readout viewable in Celsius or Fahrenheit
Factory-installed lock
Keyed lock for a secure interior
Adjustable chrome shelves
Rearrange the refrigerator space to fit any sized item or remove shelves for simple cleanup
LED lighting
Interior LED lighting offers an energy efficient view in an attractive blue hue
Flat door liner
No door shelving allows the unit to accommodate deeper items
Commercial design
Meets UL-471 electrical standards
Sealed back
Space-saving design with no exposed coils in the rear offers easy cleanability
Fully finished cabinet
Allows the unit to be used freestanding
100% CFC free
Environmentally friendly design does not contain ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet 20.25" (51 cm)
Height to Hinge Cap 20.75" (53 cm)
Width 17.0" (43 cm)
Width with Door Open 17.75" (45 cm)
Depth 19.13" (49 cm)
Depth with door at 90° 34.25" (87 cm)
Capacity 1.7 cu.ft. (48 L)
Defrost Type Automatic
Door Stainless Steel
Cabinet Stainless Steel
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Weight 55.0 lbs. (25 kg)
Shipping Weight 58.0 lbs. (26 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator Features
Door Swing RHD
Reversible Factory Reversible
Shelf Type Chrome
Shelf Qty 2
Adjustable Shelves Yes
Thermostat Type Digital
Refrigerant Type R600a
Refrigerant Amount 0.6oz.
High Side PSI 270.0
Low Side PSI 103.0
Interior Light Yes
Temperature Range 34°F to 43°F
Dimensions
Interior Height 16.5" (42 cm)
Interior Width 13.75" (35 cm)
Interior Depth 15.0" (38 cm)
Compressor Step Height 8.0" (20 cm)
Compressor Step Width 13.75" (35 cm)
Compressor Step Depth 6.0" (15 cm)

AVAILABLE UPGRADES

Exterior
DL1 - Factory installed data logger
USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
TT - Installed thermometer
ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
Latch for door
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
ODA - Open door alarm
Add an open door alarm to audibly buzz when the door is left ajar.
LHD - Left hand door swing
Door reversal to left hand swing
Extra key
Extra keys available for purchase
SCD - Self-closing door
Protect interior contents and reduce energy waste with the Self Closing Door Option
PH - Probe Hole
Factory installed probe hole for customer supplied monitoring devices
DL1 - Factory installed data logger
USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
Alarm
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
HG - Hospital grade cord
Add a hospital grade cord equipped with green dot plug with the HG suffix

DOWNLOADS

Download
USE & CARE
FF31L7BI_manual.pdf
Download
MSDS INFORMATION
MSDS_R600a_C.pdf
This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or accucoldinfo@summitappliance.com
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
