FS30L7

Delivery 9240a3e8870753a2ec143c34af2b405742ae73bfeb126dd29f201daa25ab8f11
This product qualifies for next day delivery to select areas within our trucking radius and may be shipped next day after order for nationwide customers.
Commercial meets nsf 57f181a562ef64be646d83b66028b1c5c2f384b45328a17b7b74a5f0cdc84c8e
This unit meets NSF sanitation standards for commercial use. For information on its commercial sanitation listing, see Specifications.

Meets NSF-7 standards for commercial use

24.63" H x 18.5" W x 17.75" D

(63cm H x 47cm W x 45cm D)

OVERVIEW

  • Commercially listed to NSF-7 standards
  • Compact size is ideal for countertop use
  • Factory installed lock provides added security
  • Designed for general purpose use in medical and scientific facilities
  • Reversible door offers flexible placement
  • Designed to operate at -20ºC

SPECIFICATIONS

Overview
Height of Cabinet 24.5" (62 cm)
Height to Hinge Cap 24.63" (63 cm)
Width 18.5" (47 cm)
Depth 17.75" (45 cm)
Depth with door at 90° 34.5" (88 cm)
Capacity 1.8 cu.ft. (51 L)
Defrost Type Manual
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Amps 0.8
Voltage/Frequency 115 V AC/60 Hz
Weight 43.0 lbs. (20 kg)
Shipping Weight 45.0 lbs. (20 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Freezer
Door Swing RHD
Reversible Yes
Interior Height 18.63" (47 cm)
Interior Width 13.38" (34 cm)
Interior Depth 13.0" (33 cm)
Shelf Type Wire
Shelf Qty 2
Thermostat Type Dial
Refrigerant Type R600a
Refrigerant Amount 0.8 oz.
Level Legs 2
Compressor Step Height 8.0" (20 cm)
Compressor Step Width 13.38" (34 cm)
Compressor Step Depth 5.75" (15 cm)

AVAILABLE UPGRADES

Exterior
Alarm
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
DL1 - Factory installed data logger
USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
DT - Digital thermostat
Install a digital thermostat with external readout for precise temperature management
HG - Hospital grade cord
Add a hospital grade cord equipped with green dot plug with the HG suffix
HUM - Humidity sensor
Humidity sensor with min/max readout
Latch for door
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
ODA - Open door alarm
Add an open door alarm to audibly buzz when the door is left ajar.
PH - Probe Hole
Factory installed probe hole for customer supplied monitoring devices
SCD - Self-closing door
Protect interior contents and reduce energy waste with the Self Closing Door Option
TT - Installed thermometer
ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
Extra key
Extra keys available for purchase
DL1 - Factory installed data logger
USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
Lock
AC Keypad
Keypad lock powered by appliance power cord for keyless security
KEYPAD
Battery-powered keypad lock installed for keyless security
California residents:
click here for information on Proposition 65

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or accucoldinfo@summitappliance.com

DESCRIPTION

Accucold by Summit Appliance carries a quality selection of compact freezers for general purpose use in medical facilities.

The FS30L7 is a compact 1.8 cu.ft. all-freezer that is ETL-S listed to NSF-7 commercial standards. It comes in a white exterior finish, with a factory installed lock on the user-reversible door. The interior includes removable wire shelves for optimum circulation and a one-piece interior liner to ensure easy cleanup. The dial thermostat is located inside the unit. This freezer is manual defrost and operates at an average temperature of -20ºC.

With reliable construction and a convenient size, the FS30L7 is the ideal freezer for storing select items in institutional facilities. This unit can also be ordered with more advanced medical features, including a digital thermostat, self-closing door, temperature alarm, and more.

FEATURES

Commercially approved
ETL-S listed to ANSI-NSF Standard 7 for use in commercial establishments
Compact dimensions
Sized for easy use on top of counters
Fully finished cabinet
Allows the unit to be used freestanding
Manual defrost
Static cooling system for improved temperature stability
Adjustable thermostat
Dial thermostat located inside the unit
Factory installed lock
Keyed lock for a secure interior
Reversible door
User-reversible door swing allows for more flexibility in placing the unit
Removable shelves
Wire shelves can be removed to accommodate different sizes or for easy cleanup
Flat door liner
Interior design conforms to CDC guidelines to ensure stable conditions for sensitive materials
One piece interior liner
Easy clean-up with a seamless liner that won't hold a mess in hidden crevices
100% CFC free
Environmentally friendly design without ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet 24.5" (62 cm)
Height to Hinge Cap 24.63" (63 cm)
Width 18.5" (47 cm)
Depth 17.75" (45 cm)
Depth with door at 90° 34.5" (88 cm)
Capacity 1.8 cu.ft. (51 L)
Defrost Type Manual
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Amps 0.8
Voltage/Frequency 115 V AC/60 Hz
Weight 43.0 lbs. (20 kg)
Shipping Weight 45.0 lbs. (20 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Freezer
Door Swing RHD
Reversible Yes
Interior Height 18.63" (47 cm)
Interior Width 13.38" (34 cm)
Interior Depth 13.0" (33 cm)
Shelf Type Wire
Shelf Qty 2
Thermostat Type Dial
Refrigerant Type R600a
Refrigerant Amount 0.8 oz.
Level Legs 2
Compressor Step Height 8.0" (20 cm)
Compressor Step Width 13.38" (34 cm)
Compressor Step Depth 5.75" (15 cm)

AVAILABLE UPGRADES

Exterior
Alarm
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
DL1 - Factory installed data logger
USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
DT - Digital thermostat
Install a digital thermostat with external readout for precise temperature management
HG - Hospital grade cord
Add a hospital grade cord equipped with green dot plug with the HG suffix
HUM - Humidity sensor
Humidity sensor with min/max readout
Latch for door
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
ODA - Open door alarm
Add an open door alarm to audibly buzz when the door is left ajar.
PH - Probe Hole
Factory installed probe hole for customer supplied monitoring devices
SCD - Self-closing door
Protect interior contents and reduce energy waste with the Self Closing Door Option
TT - Installed thermometer
ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
Extra key
Extra keys available for purchase
DL1 - Factory installed data logger
USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
Lock
AC Keypad
Keypad lock powered by appliance power cord for keyless security
KEYPAD
Battery-powered keypad lock installed for keyless security

DOWNLOADS

Download
BROCHURE
FS30L7.pdf
Download
MSDS INFORMATION
R600a_AO.pdf
Download
USE & CARE
FS30L_manual.pdf
California residents:
click here for information on Proposition 65

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or accucoldinfo@summitappliance.com
