18" Built-In All-Freezer, ADA Compliant

SKU: SCFF1842ADA

18" width fits well in space-challenged kitchens

31.38" H x 17.75" W x 24.0" D

(80cm H x 45cm W x 61cm D)

OVERVIEW

  • 32" height for use under lower ADA compliant counters
  • Unique 18" width is ideal for small homes and micro-kitchens
  • Fully frost-free for low maintenance operation
  • Flexible design allows built-in or freestanding use under counters
  • Digital thermostat offers precise and convenient temperature control
  • Factory-installed lock provides security you can count on
  • Adjustable chrome shelves for assorted storage options

How to Buy

SPECIFICATIONS

Overview
Height of Cabinet 31.38" (80 cm)
Width 17.75" (45 cm)
Depth 24.0" (61 cm)
Depth with Handle 25.75" (65 cm)
Depth with door at 90° 40.0" (102 cm)
Capacity 2.7 cu.ft. (76 L)
Defrost Type Frost-Free
Door Black
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Energy Usage/Year 346.0kWh/year
Amps 1.25
Voltage/Frequency 115 V AC/60 Hz
Weight 80.0 lbs. (36 kg)
Shipping Weight 83.0 lbs. (38 kg)
Estimated Time to Ship 3 to 5 days
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Freezer
Door Swing RHD
Reversible Yes
Interior Height 23.5" (60 cm)
Interior Width 12.75" (32 cm)
Interior Depth 16.75" (43 cm)
Shelf Type Chrome
Shelf Qty 4
Adjustable Shelves Yes
Thermostat Type Digital
Fan Type Interior and Exterior
Refrigerant Type R600a
Refrigerant Amount 1.06 oz.
High Side PSI 150.0
Low Side PSI 50.0
Level Legs 4
Compressor Step Height 4.5" (11 cm)
Compressor Step Width 12.75" (32 cm)
Compressor Step Depth 4.5" (11 cm)

AVAILABLE UPGRADES

Exterior
Latch for door
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
Extra key
Extra keys available for purchase
SSK
Stainless steel kickplate factory installed
This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or accucoldinfo@summitappliance.com
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.

DESCRIPTION

SUMMIT brings true convenience to small kitchen spaces with the SCFF1842ADA, an 18" wide fully frost-free all-freezer designed for use under lower ADA compliant counters.

The 32" high SCFF1842ADA is front-breathing for built-in use under counters, but also features a fully finished cabinet to allow freestanding use. The reversible door includes a factory installed lock and professional handle in stainless steel. This unit comes in a jet black finish.

Inside, the SCFF1842ADA is fully frost-free to minimize user maintenance, with slide-out chrome shelves that can be adjusted to accommodate a variety of items in the 2.7 cu.ft. interior. This unit includes a digital thermostat for easy and intuitive temperature control.

With a uniquely slim size and user-friendly features, the SCFF1842ADA is the ideal freezer for space-challenged spaces. This model meets UL-471 standards.

FEATURES

ADA compliant
Sized just under 32" high for installation under lower ADA compliant counters
Built-in capable
Make the best use of space by installing your appliance under the counter
Fully finished black cabinet
Allows the unit to be used freestanding
Frost-free operation
Eliminates the need to manually defrost the interior
Factory installed lock
Keyed security on the door
Digital thermostat
Electronic controls for precise temperature management.
Digital display
Temperature readout can be shown in Celsius or Fahrenheit
Adjustable chrome shelves
Rearrange interior space to accommodate all sizes or remove shelves for simple cleanup
Reversible door
User-reversible door swing for added flexibility
Professional handle
Stainless steel handle completes the professional look
Flush back
Space-saving design that offers easier cleanability
100% CFC Free
Environmentally friendly design with no ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet 31.38" (80 cm)
Width 17.75" (45 cm)
Depth 24.0" (61 cm)
Depth with Handle 25.75" (65 cm)
Depth with door at 90° 40.0" (102 cm)
Capacity 2.7 cu.ft. (76 L)
Defrost Type Frost-Free
Door Black
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Energy Usage/Year 346.0kWh/year
Amps 1.25
Voltage/Frequency 115 V AC/60 Hz
Weight 80.0 lbs. (36 kg)
Shipping Weight 83.0 lbs. (38 kg)
Estimated Time to Ship 3 to 5 days
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Freezer
Door Swing RHD
Reversible Yes
Interior Height 23.5" (60 cm)
Interior Width 12.75" (32 cm)
Interior Depth 16.75" (43 cm)
Shelf Type Chrome
Shelf Qty 4
Adjustable Shelves Yes
Thermostat Type Digital
Fan Type Interior and Exterior
Refrigerant Type R600a
Refrigerant Amount 1.06 oz.
High Side PSI 150.0
Low Side PSI 50.0
Level Legs 4
Compressor Step Height 4.5" (11 cm)
Compressor Step Width 12.75" (32 cm)
Compressor Step Depth 4.5" (11 cm)

AVAILABLE UPGRADES

Exterior
Latch for door
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
Extra key
Extra keys available for purchase
SSK
Stainless steel kickplate factory installed

DOWNLOADS

Download
BROCHURE w/ DRAWINGS
SCFF1842ADA.pdf
Download
TECHNICAL DRAWING (.dwg)
SCFF1842ADA_FREEZERA-C2000.dwg
Energy Guide
