16 Cu.Ft. Chest Freezer

SKU: SCFM162

Commercial meets nsf
This unit meets NSF sanitation standards for commercial use. For information on its commercial sanitation listing, see Specifications.

UL-S listed to NSF-7 standards for commercial use

33.25" H x 53.75" W x 28.63" D

(84cm H x 137cm W x 73cm D)

OVERVIEW

  • Commercially approved for use in foodservice establishments
  • Hammered aluminum interior offers added durability for long-lasting use
  • Manual defrost operation and static cooling system
  • 14.1 cu.ft. interior with removable baskets included

How to Buy

SPECIFICATIONS

Overview
Height of Cabinet 33.25" (84 cm)
Width 53.75" (137 cm)
Depth 28.63" (73 cm)
Capacity 14.1 cu.ft. (399 L)
Defrost Type Manual
Door White
Cabinet White
US Electrical Safety UL
Canadian Electrical Safety ULC
Sanitation UL-S
Amps 1.49
Voltage/Frequency 115 V AC/60 Hz
Weight 130.0 lbs. (59 kg)
Shipping Weight 140.0 lbs. (64 kg)
Estimated Time to Ship 2 to 4 days
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Freezer
Door Swing Lift-Up
Interior Height 26.25" (67 cm)
Interior Width 48.0" (122 cm)
Interior Depth 21.5" (55 cm)
Thermostat Type Dial
Refrigerant Type R134a
Refrigerant Amount 7.76 oz.
Wheels 4
Compressor Step Height 9.25" (23 cm)
Compressor Step Width 9.38" (24 cm)
Compressor Step Depth 21.5" (55 cm)
Temperature Range -30 to -12ºC/-22 to 10.4ºF

AVAILABLE UPGRADES

Lock
L-Installed Lock
Add a single key lock to the door with the L option
AC Keypad
Keypad lock powered by appliance power cord for keyless security
KEYPAD
Battery-powered keypad lock installed for keyless security
Exterior
DT - Digital thermostat
Install a digital thermostat with external readout for precise temperature management
CAS3 3" casters
3" high NSF listed casters designed for institutional use, made from non-marring hard rubber in gray finish
This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or accucoldinfo@summitappliance.com
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.

DESCRIPTION

SUMMIT COMMERCIAL offers a quality selection of manual defrost chest freezers designed for a variety of storage applications in commercial establishments.

The SCFM162 is UL-S listed to NSF-7 standards for commercial use. It comes in a white finish with stainless steel corner protectors factory installed on the exterior to ensure protection in high traffic areas. The hammered aluminum interior offers 14.1 cu.ft. of storage capacity, with two removable baskets for added convenience. This unit utilizes static manual defrost operation and includes a defrost drain.

In addition to this unit, SUMMIT COMMERICIAL offers additional sizes of commercially listed manual defrost freezers, as well as frost-free choices and low temperature freezers all approved to NSF commercial standards.

FEATURES

Commercially approved
UL-S listed to ANSI-NSF Standard 7 for commercial use
Manual defrost operation
Static cooling system
Hammered aluminum interior
Solid construction for lasting durability
Adjustable thermostat
Dial thermostat for easy temperature management
Storage baskets
Two removable plastic baskets offer convenient storage
Stainless steel front corner protectors
External "bumpers" are factory installed to protect the unit's front corners from dents
White exterior
Textured white finish fits well in any establishment
100% CFC free
Environmentally friendly design without ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet 33.25" (84 cm)
Width 53.75" (137 cm)
Depth 28.63" (73 cm)
Capacity 14.1 cu.ft. (399 L)
Defrost Type Manual
Door White
Cabinet White
US Electrical Safety UL
Canadian Electrical Safety ULC
Sanitation UL-S
Amps 1.49
Voltage/Frequency 115 V AC/60 Hz
Weight 130.0 lbs. (59 kg)
Shipping Weight 140.0 lbs. (64 kg)
Estimated Time to Ship 2 to 4 days
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Freezer
Door Swing Lift-Up
Interior Height 26.25" (67 cm)
Interior Width 48.0" (122 cm)
Interior Depth 21.5" (55 cm)
Thermostat Type Dial
Refrigerant Type R134a
Refrigerant Amount 7.76 oz.
Wheels 4
Compressor Step Height 9.25" (23 cm)
Compressor Step Width 9.38" (24 cm)
Compressor Step Depth 21.5" (55 cm)
Temperature Range -30 to -12ºC/-22 to 10.4ºF

AVAILABLE UPGRADES

Lock
L-Installed Lock
Add a single key lock to the door with the L option
AC Keypad
Keypad lock powered by appliance power cord for keyless security
KEYPAD
Battery-powered keypad lock installed for keyless security
Exterior
DT - Digital thermostat
Install a digital thermostat with external readout for precise temperature management
CAS3 3" casters
3" high NSF listed casters designed for institutional use, made from non-marring hard rubber in gray finish

DOWNLOADS

Download
BROCHURE w/ DRAWINGS
SCFM162.pdf
Download
TECHNICAL DRAWING (.dwg)
SCFM162_FREEZER__A-C_2018_.dwg
This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or accucoldinfo@summitappliance.com
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
