12" Wide 115V 2-Burner Coil Cooktop
12/15/2024
(8cm H x 30cm W x 50cm D)
SPECIFICATIONS
Overview
|
|
---|---|
Nominal Height | 3.25" (8 cm) |
Height of Cabinet | 3.25" (8 cm) |
Nominal Width | 12.0" (30 cm) |
Width | 12.0" (30 cm) |
Nominal Depth | 20.0" (51 cm) |
Depth | 19.75" (50 cm) |
Cabinet | Black |
US Electrical Safety | ETL |
Canadian Electrical Safety | ETL-C |
Amps | 12.5 |
Voltage/Frequency | 115 V AC/60 Hz |
Weight | 14.0 lbs. (6 kg) |
Parts & Labor Warranty | 1 Year |
UPC | 761101060781 |
Electric Cooktop
|
|
Heating Type | Radiant |
Surface | Porcelain |
Element Type | Coils |
Number of Elements | 2 |
Controls | Dial |
Countertop Cutout Height | 5.0" (13 cm) |
Countertop Cutout Width | 11.13" (28 cm) |
Countertop Cutout Depth | 19.13" (49 cm) |
Power Source | 115V |
Element #1 Size | 6.0" (15 cm) |
Element #1 Wattage | 600.0 |
Element #2 Size | 8.0" (20 cm) |
Element #2 Wattage | 900.0 |
Power Cord Included | Yes |
FEATURES
Designed and constructed domestically
Designed for use with 20 amp circuits
Pre-installed 115V 3-pronged cord for easier setup
Designed for 11 1/8" W x 19 1/8" D cutouts for an easy fit in smaller kitchens
Scratch-resistant design for lasting durability
Jet black exterior for an easy complement to any kitchen space
Traditional design offers reliable heating and strong durability for everyday use
Larger element is ideal for heating wider pots and pans
Standard burner accommodates most heating needs
Complies with the latest UL safety standards, the elements operate at lower wattage for slower but steadier heating that will not cycle off
Each coil element includes a removable chrome pan for easier cleaning
Curved design helps to contain spills on the surface
Knobs require a small amount of force for added safety
Upfront lights illuminate to show which burners are in use
Upfront controls and easy-to-operate knobs offer easier accessibility that complies with the Americans for Disabilities Act (ADA) guidelines
DESCRIPTION
Summit offers an extensive selection of slim-fitting cooktops designed and manufactured in the USA. The CCE212BL is a 115V cooktop with a porcelain surface in a jet black finish. Two coil elements (6" 600W in front and 8" 900W in rear) offer durable heating, with removable chrome drip pans included. The push-to-turn knobs are simple and intuitive, with indicator lights that show which burner is in use for added safety. The recessed design helps to contain spills for a cleaner cooking experience. This cooktop includes a 3-pronged 4' long power cord for convenient installation. It is designed to fit common 11 1/8" W x 19 1/8" D counter cutouts. Additional choices are available in white and stainless steel, as well as radiant, induction, and gas cooktops in similar sizes. Browse our website for our complete selection of slim-fitting cooking appliances.
Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
