24" Wide Built-In All-Refrigerator
(85cm H x 60cm W x 60cm D)
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 33.5" (85 cm) |
| Width | 23.63" (60 cm) |
| Depth | 23.5" (60 cm) |
| Depth with Handle | 25.13" (64 cm) |
| Depth with door at 90° | 46.13" (117 cm) |
| Capacity | 5.5 cu.ft. (156 L) |
| Defrost Type | Automatic |
| Door | White |
| Cabinet | White |
| US Electrical Safety | UL |
| Canadian Electrical Safety | ULC |
| Sanitation | ETL-S |
| Amps | 1.3 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
|
Refrigerator Features
|
|
| Door Swing | RHD |
| Reversible | Factory Reversible |
| Height Adjustable | 1 |
| Shelf Type | Wire |
| Shelf Qty | 3 |
| Adjustable Shelves | Yes |
| Thermostat Type | Digital |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R134a |
| Refrigerant Amount | 1.8oz. |
| High Side PSI | 285.0 |
| Low Side PSI | 70.0 |
| Level Legs Qty | 4 |
| Interior Light | Yes |
|
Dimensions
|
|
| Interior Height | 27.75" (70 cm) |
| Interior Width | 20.0" (51 cm) |
| Interior Depth | 17.5" (44 cm) |
| Compressor Step Height | 7.0" (18 cm) |
| Compressor Step Width | 20.0" (51 cm) |
| Compressor Step Depth | 6.0" (15 cm) |
AVAILABLE UPGRADES
| Door | ||
|---|---|---|
|
||
| Exterior | ||
|
||
| Lock | ||
|
FEATURES
ETL-S Listed and CalCode Compliant
Less than 24 inches wide, with a generous 5.5 c.f. of storage capacity
Make the best use of space by installing your appliance under the counter and flush with other cabinetry
Allows the unit to be used freestanding
Adjustable legs allow the unit to be sized from 33 1/2" to 34 3/4" high
Door closes automatically when opened at angles less than 90º
Keep contents secure with a front lock on the door
Secure three-pronged cord for added unit safety
Simplify maintenance by letting the appliance defrost itself
Fan-cooled interior for even temperature distribution
Electronic controls for more precise temperature management, with temperature readout and controls externally located for added convenience
Displays the current and high/low humidity readings
Rearrange the refrigerator space to fit any sized item or remove shelves for simple cleanup
An easy-to-clean flat liner accepts large trays
Temperature alarm warns of interior fluctuations while providing an external temperature readout on the door
Turn the light on when you need it and off when you're done with a a convenient switch located behind the thermostat
Environmentally friendly design does not contain ozone-damaging chemicals
DESCRIPTION
SUMMIT's ACCUCOLD™ series of refrigeration features units ideal for storage of vaccines, pharmaceuticals, and other specimens requiring safe and reliable temperature conditions. The FF7LBIMEDSC is an auto defrost refrigerator designed to fit under counters. This commercially approved white unit can be used built-in or freestanding, with a slim width just under 24" for an easy fit in tight locations. The self-closing door closes automatically when opened at angles less than 90º, an ideal feature for offices or labs where the staff may not have the time to ensure that the door is closed after use. An internal fan provides even temperature distribution, while a heat sink helps to stabilize temperature under light loads. We install an audible alarm on the door to warn of interior temperature fluctuations. Users can monitor the temperature without opening the door due to the external display. An externally mounted digital thermostat allows more control in temperature management and a humidity sensor provides the current and high/low humidity readings. The FF7LBIMEDSC has adjustable shelves, with a flat door liner to accept large trays. A green dot plug helps to protect the power cord from accidents in high traffic areas and a front lock adds keyed security. In addition to the standard features, any FF7LBIMEDSC can be customized to your exact specifications. Additional options include keypad locks, open door alarms, probe holes for specific facility monitoring, casters or dollies for portability, and more. SUMMIT sales representatives are available to help you design the perfect ACCUCOLD™ refrigerator for your storage needs.
Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
